WIRING INFORMATION: 1991 Ford Crown Victoria

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

YELLOW

Ignition Harness

STARTER WIRE

RED/LT. BLUE

Ignition Harness

IGNITION WIRE

RED/LT. GREEN

Ignition Harness

ACCESSORY WIRE

GRAY/YELLOW

Ignition Harness

SECOND ACCESSORY WIRE

GRAY/YELLOW

Ignition Harness

POWER DOOR LOCK (Models with factory
keyless entry use negative trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)

PINK/YELLOW

Harness Down Low In Drivers Kick

POWER DOOR UNLOCK (Models with
factory keyless entry use negative trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)

PINK/GREEN Harness

Down Low In Drivers Kick

PARKING LIGHTS (+)

BROWN

At Headlight Switch

HEADLIGHTS (+)

RED/YELLOW

At Headlight Switch

DOOR TRIGGER (+)

BLACK/LT.BLUE

Harness In Driver’s Kick Panel Or Under Dash
Light

TRUNK RELEASE (+)

PURPLE/YELLOW

At Trunk Release Switch

TACHOMETER WIRE

DK.GREEN/YELLOW

At Ignition Coil

BRAKE WIRE (+)

LT. GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

YELLOW/LT. GREEN

Harness At Steering Column

LEFT FRONT WINDOW UP

YELLOW

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

WHITE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

TAN/BLUE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW UP

GRAY/ORANGE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW DOWN

TAN/BLUE or YELLOW/BLUE

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW UP

RED/BLACK

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW DOWN

YELLOW/BLACK

Harness In Driver’s Kick From Driver Door


WIRING INFORMATION: 1992 Ford Crown Victoria

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

YELLOW

Ignition Harness

STARTER WIRE

RED/LT. BLUE

Ignition Harness

IGNITION WIRE

RED/LT. GREEN

Ignition Harness

ACCESSORY WIRE

GRAY/YELLOW

Ignition Harness

POWER DOOR LOCK (Models with factory
keyless entry use negative trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)

PINK/YELLOW

Harness Down Low In Drivers Kick

POWER DOOR UNLOCK (Models with
factory keyless entry use negative trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)

PINK/GREEN Harness

Down Low In Drivers Kick

PARKING LIGHTS (+)

BROWN

At Headlight Switch

HEADLIGHTS (+)

RED/YELLOW

At Headlight Switch

DOOR TRIGGER (+)

BLACK/LT.BLUE

Harness In Driver’s Kick Panel Or Under Dash
Light

DOME SUPERVISION (+)

Use Door Trigger Wire



TRUNK RELEASE (+)

PURPLE/YELLOW

At Trunk Release Switch

TACHOMETER WIRE

GRAY/ORANGE

At Ignition Coil

BRAKE WIRE (+)

LT. GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

YELLOW/LT. GREEN

Harness At Steering Column

LEFT FRONT WINDOW UP

YELLOW

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

WHITE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

TAN/BLUE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW UP

GRAY/ORANGE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW DOWN

TAN/BLUE or YELLOW/BLUE

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW UP

RED/BLACK

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW DOWN

YELLOW/BLACK

Harness In Driver’s Kick From Driver Door

Copyright 2002-2004 Triple S Customs

3


WIRING INFORMATION: 1993 Ford Crown Victoria

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

YELLOW

Ignition Harness

STARTER WIRE

RED/LT. BLUE

Ignition Harness

IGNITION WIRE

RED/LT. GREEN

Ignition Harness

ACCESSORY WIRE

GRAY/YELLOW

Ignition Harness

POWER DOOR LOCK (Models with factory
keyless entry use negative trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)

PINK/YELLOW

Harness Down Low In Drivers Kick

POWER DOOR UNLOCK (Models with
factory keyless entry use negative trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)

PINK/GREEN Harness

Down Low In Drivers Kick

PARKING LIGHTS (+)

BROWN

At Headlight Switch

HEADLIGHTS (+)

RED/YELLOW

At Headlight Switch

DOOR TRIGGER (+)

BLACK/LT.BLUE

Harness In Driver’s Kick Panel Or Under Dash
Light

DOME SUPERVISION (+)

Use Door Trigger Wire



TRUNK RELEASE (+)

PURPLE/YELLOW

At Trunk Release Switch

TACHOMETER WIRE

GRAY/ORANGE

At Ignition Coil

BRAKE WIRE (+)

LT. GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

YELLOW/LT. GREEN

Harness At Steering Column

LEFT FRONT WINDOW UP

YELLOW

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

WHITE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

TAN/BLUE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW UP

GRAY/ORANGE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW DOWN

TAN/BLUE or YELLOW/BLUE

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW UP

RED/BLACK

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW DOWN

YELLOW/BLACK

Harness In Driver’s Kick From Driver Door



Copyright 2002-2004 Triple S Customs

4

WIRING INFORMATION: 1994 Ford Crown Victoria

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

YELLOW

Ignition Harness

STARTER WIRE

RED/LT. BLUE

Ignition Harness

IGNITION WIRE

RED/LT. GREEN

Ignition Harness

ACCESSORY WIRE

GRAY/YELLOW

Ignition Harness

POWER DOOR LOCK (Models with factory
keyless entry use negative trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)

PINK/YELLOW

Harness Down Low In Drivers Kick

POWER DOOR UNLOCK (Models with
factory keyless entry use negative trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)

PINK/GREEN Harness

Down Low In Drivers Kick

PARKING LIGHTS (+)

BROWN

At Headlight Switch

HEADLIGHTS (+)

RED/YELLOW

At Headlight Switch

DOOR TRIGGER (+)

BLACK/LT.BLUE

Harness In Driver’s Kick Panel Or Under Dash
Light

DOME SUPERVISION (+)

Use Door Trigger Wire



TRUNK RELEASE (+)

PURPLE/YELLOW

At Trunk Release Switch

TACHOMETER WIRE

GRAY/ORANGE

At Ignition Coil

BRAKE WIRE (+)

LT. GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

YELLOW/LT. GREEN

Harness At Steering Column

LEFT FRONT WINDOW UP

YELLOW

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

WHITE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

TAN/BLUE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW UP

GRAY/ORANGE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW DOWN

TAN/BLUE or YELLOW/BLUE

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW UP

RED/BLACK

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW DOWN

YELLOW/BLACK

Harness In Driver’s Kick From Driver Door



Copyright 2002-2004 Triple S Customs

5

WIRING INFORMATION: 1995 Ford Crown Victoria

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

YELLOW, BROWN, GREEN

Ignition Harness

STARTER WIRE

WHITE/PINK

Ignition Harness

IGNITION WIRE

BROWN/PINK

Ignition Harness

ACCESSORY WIRE

PINK/BLACK

Ignition Harness

SECOND ACCESSORY WIRE

GRAY/YELLOW

Ignition Harness

THIRD ACCESSORY WIRE

BLACK/LT. GREEN

Ignition Harness

POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)

PINK/YELLOW

Harness In Driver’s Kick Panel

POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)

PINK/GREEN

Harness In Driver’s Kick Panel

PARKING LIGHTS (+)

BROWN

Harness In Drivers Kick Panel

DOOR TRIGGER (-)

DK.BLUE (DRIVER’S DOOR)

BLACK/ORANGE (ALL OTHER DOORS)

Module Under Dash On Driver’s Side

TRUNK RELEASE (5-wire)

PURPLE/YELLOW

Harness Coming Into Vehicle From Driver’s
Door

FACTORY ALARM DISARM (-)

DK. GREEN/PURPLE

Harness Coming Into Vehicle From Driver’s
Door

TACHOMETER WIRE

TAN/LT.GREEN, TAN/WHITE, TAN/LT.BLUE,
or TAN/ORANGE

At Ignition Coil

BRAKE WIRE (+)

LT. GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

YELLOW/LT.GREEN

Harness At Steering Column

LEFT FRONT WINDOW UP

YELLOW

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

WHITE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

TAN/BLUE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW UP

GRAY/ORANGE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW DOWN

TAN/BLUE or YELLOW/BLUE

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW UP

RED/BLACK

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW DOWN

YELLOW/BLACK

Harness In Driver’s Kick From Driver Door



Copyright 2002-2004 Triple S Customs

6

WIRING INFORMATION: 1996 Ford Crown Victoria

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

YELLOW, BROWN, GREEN

Ignition Harness

STARTER WIRE

WHITE/PINK

Ignition Harness

IGNITION WIRE

BROWN/PINK

Ignition Harness

ACCESSORY WIRE

PINK/BLACK

Ignition Harness

SECOND ACCESSORY WIRE

GRAY/YELLOW

Ignition Harness

THIRD ACCESSORY WIRE

BLACK/LT. GREEN

Ignition Harness

POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)

PINK/YELLOW

Harness In Driver’s Kick Panel

POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)

PINK/GREEN

Harness In Driver’s Kick Panel

PARKING LIGHTS (+)

BROWN

Harness In Drivers Kick Panel

DOOR TRIGGER (-)

DK.BLUE (DRIVER’S DOOR)

BLACK/ORANGE (ALL OTHER DOORS)

Module Under Dash On Driver’s Side

TRUNK RELEASE (5-wire)

PURPLE/YELLOW

Harness Coming Into Vehicle From Driver’s
Door

FACTORY ALARM DISARM (-)

DK. GREEN/PURPLE

Harness Coming Into Vehicle From Driver’s
Door

TACHOMETER WIRE

TAN/LT.GREEN, TAN/WHITE, TAN/LT.BLUE,
or TAN/ORANGE

At Ignition Coil

BRAKE WIRE (+)

LT. GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

YELLOW/LT.GREEN

Harness At Steering Column

LEFT FRONT WINDOW UP

YELLOW

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

WHITE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

TAN/BLUE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW UP

GRAY/ORANGE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW DOWN

TAN/BLUE or YELLOW/BLUE

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW UP

RED/BLACK

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW DOWN

YELLOW/BLACK

Harness In Driver’s Kick From Driver Door



Copyright 2002-2004 Triple S Customs

7

WIRING INFORMATION: 1997 Ford Crown Victoria

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

YELLOW, BROWN, GREEN

Ignition Harness

STARTER WIRE

WHITE/PINK

Ignition Harness

IGNITION WIRE

BROWN/PINK

Ignition Harness

ACCESSORY WIRE

PINK/BLACK

Ignition Harness

SECOND ACCESSORY WIRE

GRAY/YELLOW

Ignition Harness

THIRD ACCESSORY WIRE

BLACK/LT. GREEN

Ignition Harness

POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)

PINK/YELLOW

Harness In Driver’s Kick Panel

POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)

PINK/GREEN

Harness In Driver’s Kick Panel

PARKING LIGHTS (+)

BROWN

Harness In Drivers Kick Panel

DOOR TRIGGER (-)

DK.BLUE (DRIVER’S DOOR)

BLACK/ORANGE (ALL OTHER DOORS)

Module Under Dash On Driver’s Side

TRUNK RELEASE (5-wire)

PURPLE/YELLOW

Harness Coming Into Vehicle From Driver’s
Door

FACTORY ALARM DISARM (-)

DK. GREEN/PURPLE

Harness Coming Into Vehicle From Driver’s
Door

TACHOMETER WIRE

TAN/LT.GREEN, TAN/WHITE, TAN/LT.BLUE,
or TAN/ORANGE

At Ignition Coil

BRAKE WIRE (+)

LT. GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

YELLOW/LT.GREEN

Harness At Steering Column

LEFT FRONT WINDOW UP

YELLOW

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

WHITE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

TAN/BLUE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW UP

GRAY/ORANGE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW DOWN

TAN/BLUE or YELLOW/BLUE

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW UP

RED/BLACK

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW DOWN

YELLOW/BLACK

Harness In Driver’s Kick From Driver Door



Copyright 2002-2004 Triple S Customs

8

WIRING INFORMATION: 1998 Ford Crown Victoria

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

BROWN and LT.GREEN

Ignition Harness

STARTER WIRE

WHITE/PINK

Ignition Harness

IGNITION WIRE

BROWN/PINK

Ignition Harness

SECOND IGNITION WIRE

GRAY/YELLOW

Ignition Harness

ACCESSORY WIRE

BLACK/LT.GREEN

Ignition Harness

SECOND ACCESSORY WIRE

PINK/BLACK

Ignition Harness

POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)

PINK/YELLOW

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)

PINK/GREEN

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BROWN

Module Under Dash On Right Side Of
Steering Column

DOOR TRIGGER (-)

BLUE (DRIVER’S DOOR)

BLACK/ORANGE (ALL OTHER DOORS)

Module Under Dash On Right Side Of
Steering Column

DOME SUPERVISION (+)

BLACK/LT. BLUE

Module Under Dash On Right Side Of
Steering Column

TRUNK TRIGGER (-)

BROWN/WHITE

Module Under Dash On Right Side Of
Steering Column

TRUNK RELEASE (5-wire)

PURPLE/YELLOW

Harness Coming Into Vehicle From Driver’s
Door

TACHOMETER WIRE

WHITE/PINK

At Power Train Module On Driver’s Side Of
Engine Bay

BRAKE WIRE (+)

LT. GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

DK.BLUE

Module Under Dash On Right Side Of
Steering Column

LEFT FRONT WINDOW UP

YELLOW

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

WHITE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

TAN/BLUE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW UP

GRAY/ORANGE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW DOWN

TAN/BLUE or YELLOW/BLUE

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW UP

RED/BLACK

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW DOWN

YELLOW/BLACK

Harness In Driver’s Kick From Driver Door

This vehicle may be equipped with PATS anti-theft system. This must be bypassed when installing a remote start system.



Copyright 2002-2004 Triple S Customs

9

WIRING INFORMATION: 1999 Ford Crown Victoria

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

BROWN and LT.GREEN

Ignition Harness

STARTER WIRE

WHITE/PINK

Ignition Harness

IGNITION WIRE

BROWN/PINK

Ignition Harness

SECOND IGNITION WIRE

GRAY/YELLOW

Ignition Harness

ACCESSORY WIRE

BLACK/LT.GREEN

Ignition Harness

SECOND ACCESSORY WIRE

PINK/BLACK

Ignition Harness

POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)

PINK/YELLOW

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)

PINK/GREEN

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BROWN

Module Under Dash On Right Side Of
Steering Column

DOOR TRIGGER (-)

BLUE (DRIVER’S DOOR)

BLACK/ORANGE (ALL OTHER DOORS)

Module Under Dash On Right Side Of
Steering Column

DOME SUPERVISION (+)

BLACK/LT. BLUE

Module Under Dash On Right Side Of
Steering Column

TRUNK TRIGGER (-)

BROWN/WHITE

Module Under Dash On Right Side Of
Steering Column

TRUNK RELEASE (5-wire)

PURPLE/YELLOW

Harness Coming Into Vehicle From Driver’s
Door

TACHOMETER WIRE

WHITE/PINK

At Power Train Module On Driver’s Side Of
Engine Bay

BRAKE WIRE (+)

LT. GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

DK.BLUE

Module Under Dash On Right Side Of
Steering Column

LEFT FRONT WINDOW UP

YELLOW

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

WHITE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

TAN/BLUE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW UP

GRAY/ORANGE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW DOWN

TAN/BLUE or YELLOW/BLUE

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW UP

RED/BLACK

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW DOWN

YELLOW/BLACK

Harness In Driver’s Kick From Driver Door

LEFT FRONT WINDOW UP

YELLOW

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

WHITE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

TAN/BLUE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW UP

GRAY/ORANGE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW DOWN

TAN/BLUE or YELLOW/BLUE

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW UP

RED/BLACK

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW DOWN

YELLOW/BLACK

Harness In Driver’s Kick From Driver Door

This vehicle may be equipped with PATS anti-theft system. This must be bypassed when installing a remote start system.



Copyright 2002-2004 Triple S Customs

10

WIRING INFORMATION: 2000 Ford Crown Victoria

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

BROWN and LT.GREEN

Ignition Harness

STARTER WIRE

WHITE/PINK

Ignition Harness

IGNITION WIRE

BROWN/PINK

Ignition Harness

SECOND IGNITION WIRE

GRAY/YELLOW

Ignition Harness

ACCESSORY WIRE

BLACK/LT.GREEN

Ignition Harness

SECOND ACCESSORY WIRE

PINK/BLACK

Ignition Harness

POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)

PINK/YELLOW

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)

PINK/GREEN

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BROWN

Module Under Dash On Right Side Of
Steering Column

DOOR TRIGGER (-)

BLUE (DRIVER’S DOOR)

BLACK/ORANGE (ALL OTHER DOORS)

Module Under Dash On Right Side Of
Steering Column

DOME SUPERVISION (+)

BLACK/LT. BLUE

Module Under Dash On Right Side Of
Steering Column

TRUNK TRIGGER (-)

BROWN/WHITE

Module Under Dash On Right Side Of
Steering Column

TRUNK RELEASE (5-wire)

PURPLE/YELLOW

Harness Coming Into Vehicle From Driver’s
Door

TACHOMETER WIRE

WHITE/PINK

At Power Train Module On Driver’s Side Of
Engine Bay

BRAKE WIRE (+)

LT. GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

DK.BLUE

Module Under Dash On Right Side Of
Steering Column

LEFT FRONT WINDOW UP

YELLOW

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

WHITE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

TAN/BLUE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW UP

GRAY/ORANGE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW DOWN

TAN/BLUE or YELLOW/BLUE

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW UP

RED/BLACK

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW DOWN

YELLOW/BLACK

Harness In Driver’s Kick From Driver Door

This vehicle may be equipped with PATS anti-theft system. This must be bypassed when installing a remote start system.



Copyright 2002-2004 Triple S Customs

11

WIRING INFORMATION: 2001 Ford Crown Victoria

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

BROWN and LT.GREEN

Ignition Harness

STARTER WIRE

WHITE/PINK

Ignition Harness

IGNITION WIRE

BROWN/PINK

Ignition Harness

SECOND IGNITION WIRE

GRAY/YELLOW

Ignition Harness

ACCESSORY WIRE

BLACK/LT.GREEN

Ignition Harness

SECOND ACCESSORY WIRE

PINK/BLACK

Ignition Harness

POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)

PINK/YELLOW

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)

PINK/GREEN

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BROWN

Module Under Dash On Right Side Of
Steering Column

DOOR TRIGGER (-)

BLUE (DRIVER’S DOOR)

BLACK/ORANGE (ALL OTHER DOORS)

Module Under Dash On Right Side Of
Steering Column

DOME SUPERVISION (+)

BLACK/LT. BLUE

Module Under Dash On Right Side Of
Steering Column

TRUNK TRIGGER (-)

BROWN/WHITE

Module Under Dash On Right Side Of
Steering Column

TRUNK RELEASE (5-wire)

PURPLE/YELLOW

Harness Coming Into Vehicle From Driver’s
Door

TACHOMETER WIRE

WHITE/PINK

At Power Train Module On Driver’s Side Of
Engine Bay

BRAKE WIRE (+)

LT. GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

DK.BLUE

Module Under Dash On Right Side Of
Steering Column

LEFT FRONT WINDOW UP

YELLOW

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

WHITE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

TAN/BLUE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW UP

GRAY/ORANGE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW DOWN

TAN/BLUE or YELLOW/BLUE

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW UP

RED/BLACK

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW DOWN

YELLOW/BLACK

Harness In Driver’s Kick From Driver Door

This vehicle may be equipped with PATS anti-theft system. This must be bypassed when installing a remote start system.



Copyright 2002-2004 Triple S Customs

12

WIRING INFORMATION: 2002 Ford Crown Victoria

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

BROWN and LT.GREEN

Ignition Harness

STARTER WIRE

WHITE/PINK

Ignition Harness

IGNITION WIRE

BROWN/PINK

Ignition Harness

SECOND IGNITION WIRE

GRAY/YELLOW

Ignition Harness

ACCESSORY WIRE

BLACK/LT.GREEN

Ignition Harness

SECOND ACCESSORY WIRE

PINK/BLACK

Ignition Harness

POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)

PINK/YELLOW

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)

PINK/GREEN

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BROWN

Module Under Dash On Right Side Of
Steering Column

DOOR TRIGGER (-)

BLUE (DRIVER’S DOOR)

BLACK/ORANGE (ALL OTHER DOORS)

Module Under Dash On Right Side Of
Steering Column

DOME SUPERVISION (+)

BLACK/LT. BLUE

Module Under Dash On Right Side Of
Steering Column

TRUNK TRIGGER (-)

BROWN/WHITE

Module Under Dash On Right Side Of
Steering Column

TRUNK RELEASE (5-wire)

PURPLE/YELLOW

Harness Coming Into Vehicle From Driver’s
Door

TACHOMETER WIRE

WHITE/PINK

At Power Train Module On Driver’s Side Of
Engine Bay

BRAKE WIRE (+)

LT. GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

DK.BLUE

Module Under Dash On Right Side Of
Steering Column

LEFT FRONT WINDOW UP

YELLOW

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

WHITE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

TAN/BLUE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW UP

GRAY/ORANGE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW DOWN

TAN/BLUE or YELLOW/BLUE

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW UP

RED/BLACK

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW DOWN

YELLOW/BLACK

Harness In Driver’s Kick From Driver Door

This vehicle may be equipped with PATS anti-theft system. This must be bypassed when installing a remote start system.



Copyright 2002-2004 Triple S Customs

13

WIRING INFORMATION: 2003 Ford Crown Victoria

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

BROWN and LT.GREEN

Ignition Harness

STARTER WIRE

RED/LT.BLUE

Ignition Harness

IGNITION WIRE

WHITE/YELLOW

Ignition Harness

ACCESSORY WIRE

BLACK/LT.GREEN

Ignition Harness

SECOND ACCESSORY WIRE

PINK/BLACK

Ignition Harness

THIRD ACCESSORY WIRE

GRAY/YELLOW

Ignition Harness

POWER DOOR LOCK (Models with factory
keyless entry use positive trigger power door
locks. Models without factory keyless entry
use a reverse-polarity door lock system
mastered from the passenger switch)

PINK/YELLOW

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (Models with
factory keyless entry use positive trigger
power door locks. Models without factory
keyless entry use a reverse-polarity door lock
system mastered from the passenger switch)

PINK/GREEN

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BROWN

Module Under Dash On Right Side Of
Steering Column

DOOR TRIGGER (-)

BLUE (DRIVER’S DOOR)

BLACK/ORANGE (ALL OTHER DOORS)

Module Under Dash On Right Side Of
Steering Column

TRUNK TRIGGER (-)

BROWN/WHITE

Module Under Dash On Right Side Of
Steering Column

TRUNK RELEASE (5-wire)

PURPLE/YELLOW

Harness Coming Into Vehicle From Driver’s
Door

TACHOMETER WIRE

Wire that is NOT RED or RED/GREEN

Any Ignition Coil

BRAKE WIRE (+)

LT. GREEN

At Brake Pedal Switch

HORN TRIGGER (-)

DK.BLUE

Module Under Dash On Right Side Of
Steering Column

LEFT FRONT WINDOW UP

YELLOW

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

WHITE/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

WHITE/YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

TAN/BLUE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW UP

GRAY/ORANGE

Harness In Driver’s Kick From Driver Door

LEFT REAR WINDOW DOWN

TAN/BLUE or YELLOW/BLUE

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW UP

RED/BLACK

Harness In Driver’s Kick From Driver Door

RIGHT REAR WINDOW DOWN

YELLOW/BLACK

Harness In Driver’s Kick From Driver Door

This vehicle may be equipped with PATS anti-theft system. This must be bypassed when installing a remote start system.
