Copyright 2002-2004 Triple S Customs



GMC VAN 1985-2002

V

V

E

E

H

H

I

I

C

C

L

L

E

E





W

W

I

I

R

R

I

I

N

N

G

G




























Copyright 2002-2004 Triple S Customs



2

WIRING INFORMATION: 1985 GMC Vandura

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW OR PURPLE

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness In Drivers Kick Panel

POWER DOOR UNLOCK (+)

BLACK/WHITE

Harness In Drivers Kick Panel

PARKING LIGHTS (+)

BROWN

At Headlight Switch Or Harness In Drivers
Kick Panel

HEADLIGHTS (+)

YELLOW

At Headlight Switch

DOOR TRIGGER (-)

WHITE

At Door Pin Or Under Dash Light

REAR DOOR TRIGGER

COMMON WITH DOORS



TACHOMETER WIRE

WHITE

At Ignition Coil

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Harness At Steering Column

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

BLUE/WHITE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door


WIRING INFORMATION: 1986 GMC Vandura

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW OR PURPLE

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness In Drivers Kick Panel

POWER DOOR UNLOCK (+)

BLACK/WHITE

Harness In Drivers Kick Panel

PARKING LIGHTS (+)

BROWN

At Headlight Switch Or Harness In Drivers
Kick Panel

HEADLIGHTS (+)

YELLOW

At Headlight Switch

DOOR TRIGGER (-)

WHITE

At Door Pin Or Under Dash Light

REAR DOOR TRIGGER

COMMON WITH DOORS



TACHOMETER WIRE

WHITE

At Ignition Coil

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Harness At Steering Column

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

BLUE/WHITE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door


WIRING INFORMATION: 1987 GMC Vandura

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW OR PURPLE

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness In Drivers Kick Panel

POWER DOOR UNLOCK (+)

BLACK/WHITE

Harness In Drivers Kick Panel

PARKING LIGHTS (+)

BROWN

At Headlight Switch Or Harness In Drivers
Kick Panel

HEADLIGHTS (+)

YELLOW

At Headlight Switch

DOOR TRIGGER (-)

WHITE

At Door Pin Or Under Dash Light

REAR DOOR TRIGGER

COMMON WITH DOORS



TACHOMETER WIRE

WHITE

At Ignition Coil

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Harness At Steering Column

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

BLUE/WHITE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door

Copyright 2002-2004 Triple S Customs



3



WIRING INFORMATION: 1988 GMC Vandura

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW OR PURPLE

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness In Drivers Kick Panel

POWER DOOR UNLOCK (+)

BLACK/WHITE

Harness In Drivers Kick Panel

PARKING LIGHTS (+)

BROWN

At Headlight Switch Or Harness In Drivers
Kick Panel

HEADLIGHTS (+)

YELLOW

At Headlight Switch

DOOR TRIGGER (-)

WHITE

At Door Pin Or Under Dash Light

REAR DOOR TRIGGER

COMMON WITH DOORS



TACHOMETER WIRE

WHITE

At Ignition Coil

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Harness At Steering Column

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

BLUE/WHITE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door


WIRING INFORMATION: 1989 GMC Vandura

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW OR PURPLE

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness In Drivers Kick Panel

POWER DOOR UNLOCK (+)

BLACK/WHITE

Harness In Drivers Kick Panel

PARKING LIGHTS (+)

BROWN

At Headlight Switch Or Harness In Drivers
Kick Panel

HEADLIGHTS (+)

YELLOW

At Headlight Switch

DOOR TRIGGER (-)

WHITE

At Door Pin Or Under Dash Light

REAR DOOR TRIGGER

COMMON WITH DOORS



TACHOMETER WIRE

WHITE

At Ignition Coil

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Harness At Steering Column

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

BLUE/WHITE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door



WIRING INFORMATION: 1990 GMC Vandura

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW OR PURPLE

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness In Drivers Kick Panel

POWER DOOR UNLOCK (+)

BLACK/WHITE

Harness In Drivers Kick Panel

PARKING LIGHTS (+)

BROWN

At Headlight Switch Or Harness In Drivers
Kick Panel

DOOR TRIGGER (-)

WHITE

At Door Pin Or Under Dash Light

REAR DOOR TRIGGER

COMMON WITH DOORS



TACHOMETER WIRE

WHITE

At Ignition Coil

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Harness At Steering Column

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

BLUE/WHITE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door

Copyright 2002-2004 Triple S Customs



4



WIRING INFORMATION: 1991 GMC Vandura

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW OR PURPLE

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness In Drivers Kick Panel

POWER DOOR UNLOCK (+)

BLACK/WHITE

Harness In Drivers Kick Panel

PARKING LIGHTS (+)

BROWN

At Headlight Switch Or Harness In Drivers
Kick Panel

DOOR TRIGGER (-)

WHITE

At Door Pin Or Under Dash Light

REAR DOOR TRIGGER

COMMON WITH DOORS



TACHOMETER WIRE

WHITE

At Ignition Coil

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Harness At Steering Column

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

BLUE/WHITE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door


WIRING INFORMATION: 1992 GMC Vandura

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW OR PURPLE

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness In Drivers Kick Panel

POWER DOOR UNLOCK (+)

BLACK/WHITE

Harness In Drivers Kick Panel

PARKING LIGHTS (+)

BROWN

At Headlight Switch Or Harness In Drivers
Kick Panel

DOOR TRIGGER (-)

WHITE

At Door Pin Or Under Dash Light

REAR DOOR TRIGGER

COMMON WITH DOORS



TACHOMETER WIRE

WHITE

At Ignition Coil

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Harness At Steering Column

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

BLUE/WHITE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door


WIRING INFORMATION: 1993 GMC Vandura

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW OR PURPLE

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness In Drivers Kick Panel

POWER DOOR UNLOCK (+)

BLACK/WHITE

Harness In Drivers Kick Panel

PARKING LIGHTS (+)

BROWN

At Headlight Switch Or Harness In Drivers
Kick Panel

DOOR TRIGGER (-)

WHITE

At Door Pin Or Under Dash Light

REAR DOOR TRIGGER

COMMON WITH DOORS



TACHOMETER WIRE

WHITE

At Ignition Coil

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Harness At Steering Column

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

BLUE/WHITE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door



Copyright 2002-2004 Triple S Customs



5

WIRING INFORMATION: 1994 GMC Vandura

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

PURPLE

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

In Harness Coming Into Vehicle From
Driver’s Door Or Behind Instrument Cluster

POWER DOOR UNLOCK (+)

BLACK

In Harness Coming Into Vehicle From
Driver’s Door Or Behind Instrument Cluster

PARKING LIGHTS (+)

BROWN

At Head Light Switch

HEADLIGHTS (+)

YELLOW

At Head Light Switch

DOOR TRIGGER (-)

WHITE

At Door Pin Switch

REAR DOOR TRIGGER

TIED IN WITH DOORS



TACHOMETER WIRE

WHITE

At Ignition Coil

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Harness At Steering Column

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

BLUE/WHITE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door







WIRING INFORMATION: 1995 GMC Vandura

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED OR RED/WHITE

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

SECOND IGNITION WIRE

PINK/WHITE OR WHITE

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (+)

WHITE

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BROWN

At Head Light Switch

HEADLIGHTS (+)

YELLOW

At Head Light Switch

DOOR TRIGGER (-)

PURPLE

Harness Coming Into Vehicle From Driver’s
Door

REAR DOOR TRIGGER (-)

ORANGE/BLACK

At Light In Rear Cargo Area

TACHOMETER WIRE

WHITE

Module Under Hood On Driver’s Inner Fender
Well

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Above Ignition Harness

DIESEL WAIT-TO-START (-)

DARK BLUE

Instrument Cluster

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

BLUE/WHITE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door







Copyright 2002-2004 Triple S Customs



6

WIRING INFORMATION: 1996 GMC Savana Van

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED OR RED/WHITE

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

SECOND IGNITION WIRE

PINK/WHITE OR WHITE

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (+)

WHITE

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BROWN

At Head Light Switch

HEADLIGHTS (+)

YELLOW

At Head Light Switch

DOOR TRIGGER (-)

PURPLE

Harness Coming Into Vehicle From Driver’s
Door

REAR DOOR TRIGGER (-)

ORANGE/BLACK

At Light In Rear Cargo Area

TACHOMETER WIRE

WHITE

Module Under Hood On Driver’s Inner Fender
Well

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Above Ignition Harness

DIESEL WAIT-TO-START (-)

DARK BLUE

Instrument Cluster

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

LIGHT BLUE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door


WIRING INFORMATION: 1997 GMC Savana Van

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED OR RED/WHITE

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

SECOND IGNITION WIRE

PINK/WHITE OR WHITE

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (+)

WHITE

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BROWN

At Head Light Switch

HEADLIGHTS (+)

YELLOW

At Head Light Switch

DOOR TRIGGER (-)

PURPLE

Harness Coming Into Vehicle From Driver’s
Door

REAR DOOR TRIGGER (-)

ORANGE/BLACK

At Light In Rear Cargo Area

TACHOMETER WIRE

WHITE

Module Under Hood On Driver’s Inner Fender
Well

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Above Ignition Harness

DIESEL WAIT-TO-START (-)

DARK BLUE

Instrument Cluster

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

LIGHT BLUE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door

Copyright 2002-2004 Triple S Customs



7


WIRING INFORMATION: 1998 GMC Savana Van

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED OR RED/WHITE

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

SECOND IGNITION WIRE

PINK/WHITE OR WHITE

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (+)

WHITE

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BROWN

At Head Light Switch

HEADLIGHTS (+)

YELLOW

At Head Light Switch

DOOR TRIGGER (-)

PURPLE

Harness Coming Into Vehicle From Driver’s
Door

REAR DOOR TRIGGER (-)

ORANGE/BLACK

At Light In Rear Cargo Area

TACHOMETER WIRE

WHITE

Module Under Hood On Driver’s Inner Fender
Well

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Above Ignition Harness

DIESEL WAIT-TO-START (-)

DARK BLUE

Instrument Cluster

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

LIGHT BLUE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door

This vehicle is equipped with the Passlock II anti-theft system. This must be bypassed when installing a remote start system.


WIRING INFORMATION: 1999 GMC Savana Van

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED OR RED/WHITE

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

SECOND IGNITION WIRE

PINK/WHITE OR WHITE

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (+)

WHITE

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BROWN

At Head Light Switch

HEADLIGHTS (+)

YELLOW

At Head Light Switch

DOOR TRIGGER (-)

PURPLE

Harness Coming Into Vehicle From Driver’s
Door

REAR DOOR TRIGGER (-)

ORANGE/BLACK

At Light In Rear Cargo Area

TACHOMETER WIRE

WHITE

Module Under Hood On Driver’s Inner Fender
Well

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Above Ignition Harness

DIESEL WAIT-TO-START (-)

DARK BLUE

Instrument Cluster

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

LIGHT BLUE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door

This vehicle is equipped with the Passlock II anti-theft system. This must be bypassed when installing a remote start system.


Copyright 2002-2004 Triple S Customs



8


WIRING INFORMATION: 2000 GMC Savana Van

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED OR RED/WHITE

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

SECOND IGNITION WIRE

PINK/WHITE OR WHITE

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (+)

WHITE

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BROWN

At Head Light Switch

HEADLIGHTS (+)

YELLOW

At Head Light Switch

DOOR TRIGGER (-)

PURPLE

Harness Coming Into Vehicle From Driver’s
Door

REAR DOOR TRIGGER (-)

ORANGE/BLACK

At Light In Rear Cargo Area

TACHOMETER WIRE

WHITE

Module Under Hood On Driver’s Inner Fender
Well

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Above Ignition Harness

DIESEL WAIT-TO-START (-)

DARK BLUE

Instrument Cluster

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

LIGHT BLUE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door

This vehicle is equipped with the Passlock II anti-theft system. This must be bypassed when installing a remote start system.




WIRING INFORMATION: 2001 GMC Savana Van

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED OR RED/WHITE

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

SECOND IGNITION WIRE

PINK/WHITE OR WHITE

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (+)

WHITE

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BROWN

At Head Light Switch

HEADLIGHTS (+)

YELLOW

At Head Light Switch

DOOR TRIGGER (-)

PURPLE

Harness Coming Into Vehicle From Driver’s
Door

REAR DOOR TRIGGER (-)

ORANGE/BLACK

At Light In Rear Cargo Area

TACHOMETER WIRE

WHITE

Module Under Hood On Driver’s Inner Fender
Well

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Above Ignition Harness

DIESEL WAIT-TO-START (-)

DARK BLUE

Instrument Cluster

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

LIGHT BLUE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door

This vehicle is equipped with the Passlock II anti-theft system. This must be bypassed when installing a remote start system.


Copyright 2002-2004 Triple S Customs



9



WIRING INFORMATION: 2002 GMC Savana Van

WIRE

WIRE COLOR

WIRE LOCATION

12V CONSTANT WIRE

RED OR RED/WHITE

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

IGNITION WIRE

PINK

Ignition Harness

SECOND IGNITION WIRE

PINK/WHITE OR WHITE

Ignition Harness

ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT. BLUE

Harness Coming Into Vehicle From Driver’s
Door

POWER DOOR UNLOCK (+)

WHITE

Harness Coming Into Vehicle From Driver’s
Door

PARKING LIGHTS (+)

BROWN

At Head Light Switch

HEADLIGHTS (+)

YELLOW

At Head Light Switch

DOOR TRIGGER (-)

PURPLE

Harness Coming Into Vehicle From Driver’s
Door

REAR DOOR TRIGGER (-)

ORANGE/BLACK

At Light In Rear Cargo Area

TACHOMETER WIRE

WHITE

Module Under Hood On Driver’s Inner Fender
Well

BRAKE WIRE (+)

WHITE

At Brake Pedal Switch

HORN TRIGGER (-)

BLACK

Above Ignition Harness

DIESEL WAIT-TO-START (-)

DARK BLUE

Instrument Cluster

LEFT FRONT WINDOW UP

DARK BLUE

At Motor Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Motor Inside Driver’s Door

RIGHT FRONT WINDOW UP

LIGHT BLUE

Harness In Driver’s Kick Panel From Driver
Door

RIGHT FRONT WINDOW DOWN

TAN

Harness In Driver’s Kick Panel From Driver
Door

This vehicle is equipped with the Passlock II anti-theft system. This must be bypassed when installing a remote start system.
