DOSSIER MECANIQUE :

TABLE DE

DECOUPE POUR

LE POLYSTYRENE

AERO CLUB DE BELLEGARDE

SECTION MODELE REDUIT

Janvier 1999

[Découpe CNC]

Joseph Vianello

Francois Blanc

Didier Lanot

Gérard Prat
