HYUNDAI EXCEL 1990-1994

V

V

E

E

H

H

I

I

C

C

L

L

E

E





W

W

I

I

R

R

I

I

N

N

G

G




























Copyright 2002-2004 Triple S Customs

2

WIRING INFORMATION 1990 Hyundai Excel

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

BLACK/BLUE

Ignition harness

12V IGNITION WIRE

BLACK/WHITE

Ignition harness

12V ACCESSORY WIRE

BLUE

Ignition harness

STARTER WIRE

BLACK/YELLOW OR BLACK/RED

Ignition harness

PARKING LIGHTS (+)

GREEN/WHITE

Yellow Connector Above Fuse Box

DOOR TRIGGER/ DOMELIGHT
SUPERVISION (-)

BLACK/RED

In “A” Pillar Or Behind Instrument Cluster

TRUNK TRIGGER (-)

BROWN/RED

Harness Left Of Steering Column

TACHOMETER WIRE

WHITE/YELLOW

At Ignition Coil

BRAKE WIRE (+)

GREEN

Harness At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/WHITE

Harness At Steering Column


WIRING INFORMATION 1991 Hyundai Excel

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

BLACK/BLUE

Ignition harness

12V IGNITION WIRE

BLACK/WHITE

Ignition harness

12V ACCESSORY WIRE

BLUE

Ignition harness

STARTER WIRE

BLACK/YELLOW OR BLACK/RED

Ignition harness

PARKING LIGHTS (+)

GREEN/WHITE

Yellow Connector Above Fuse Box

DOOR TRIGGER/ DOMELIGHT
SUPERVISION (-)

BLACK/RED

In “A” Pillar Or Behind Instrument Cluster

TRUNK TRIGGER (-)

BROWN/RED

Harness Left Of Steering Column

TACHOMETER WIRE

WHITE/YELLOW

At Ignition Coil

BRAKE WIRE (+)

GREEN

Harness At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/WHITE

Harness At Steering Column


WIRING INFORMATION 1992 Hyundai Excel

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

BLACK/BLUE

Ignition harness

12V IGNITION WIRE

BLACK/WHITE

Ignition harness

12V ACCESSORY WIRE

BLUE

Ignition harness

STARTER WIRE

BLACK/YELLOW OR BLACK/RED

Ignition harness

PARKING LIGHTS (+)

GREEN/WHITE

Yellow Connector Above Fuse Box

DOOR TRIGGER/ DOMELIGHT
SUPERVISION (-)

BLACK/RED

In “A” Pillar Or Behind Instrument Cluster

TRUNK TRIGGER (-)

BROWN/RED

Harness Left Of Steering Column

TACHOMETER WIRE

WHITE/YELLOW

At Ignition Coil

BRAKE WIRE (+)

GREEN

Harness At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/WHITE

Harness At Steering Column


WIRING INFORMATION 1993 Hyundai Excel

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

BLACK/BLUE

Ignition harness

12V IGNITION WIRE

BLACK/WHITE

Ignition harness

12V ACCESSORY WIRE

BLUE

Ignition harness

STARTER WIRE

BLACK/YELLOW OR BLACK/RED

Ignition harness

PARKING LIGHTS (+)

GREEN/WHITE

Yellow Connector Above Fuse Box

DOOR TRIGGER/ DOMELIGHT
SUPERVISION (-)

BLACK/RED

In “A” Pillar Or Behind Instrument Cluster

TRUNK TRIGGER (-)

BROWN/RED

Harness Left Of Steering Column

TACHOMETER WIRE

WHITE/YELLOW

At Ignition Coil

BRAKE WIRE (+)

GREEN

Harness At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/WHITE

Harness At Steering Column



Copyright 2002-2004 Triple S Customs

3

WIRING INFORMATION 1994 Hyundai Excel

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

BLACK/BLUE

Ignition harness

12V IGNITION WIRE

BLACK/WHITE

Ignition harness

12V ACCESSORY WIRE

BLUE

Ignition harness

STARTER WIRE

BLACK/YELLOW OR BLACK/RED

Ignition harness

PARKING LIGHTS (+)

GREEN/WHITE

Yellow Connector Above Fuse Box

DOOR TRIGGER/ DOMELIGHT
SUPERVISION (-)

BLACK/RED

In “A” Pillar Or Behind Instrument Cluster

TRUNK TRIGGER (-)

BROWN/RED

Harness Left Of Steering Column

TACHOMETER WIRE

WHITE/YELLOW

At Ignition Coil

BRAKE WIRE (+)

GREEN

Harness At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/WHITE

Harness At Steering Column
