100 Corporate Drive Mahwah, NJ 07430













Service Bulletin



No. :  OST-F1176
Date:

 December 17, 2009

_____________________________________________________________





Model:



DCM-290, DCM-390,  DCM-27, DCM-500AE













Subject:

Replacement of the defective Optical Pick-up.





















Symptom:

 The unit is incapable of reading the TOC after loading the disc.




Solution:

The production process has been improved so that the Optical

Pick-up is protected from deterioration.



Parts:



Ref# Description

Part

Number

MECHA

ASS’Y

MECHA ASS’Y

KSM213CCM

00D 958 0002 503




Serial Number Range:

(last 5 digits)

DCM-290

00011 ~ 09110

DCM-390

00011 ~ 04310

DCM-27

00011 ~ 02510

DCM-500AE  00001 ~ 04200
